Model / SKU: ACU[H]B-VAR
![ACU[H]B | High Gain Antenna With Phasing Coil](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/PIC_ACUHB-VAR.webp "ACU[H]B | High Gain Antenna With Phasing Coil")
The ACUHB offers high gain and a rugged design to create an efficient
and durable product. The hinge adaptor ensures that the antenna can
always be correctly polarised even when installed on non-horizontal
ground planes and protects the antenna from damage in low clearance
situations.
7dBi peak gain will offer a significant boost to performance in remote
or edge of cell locations but due to narrow bandwidth lower gain
antennas will be more suitable for urban or suburban locations.
The ACUHB offers high gain and a rugged design to create an efficient and durable product. The hinge adaptor ensures that the antenna can always be correctly polarised even when installed on non-horizontal ground planes and protects the antenna from damage in low clearance situations. 7dBi peak gain will offer a significant boost to performance in remote or edge of cell locations but due to narrow bandwidth lower gain antennas will be more suitable for urban or suburban locations.
The ACUHB offers high gain and a rugged design to create an efficient and durable product. The hinge adaptor ensures that the antenna can always be correctly polarised even when installed on non-horizontal ground planes and protects the antenna from damage in low clearance situations.
7dBi peak gain will offer a significant boost to performance in remote or edge of cell locations but due to narrow bandwidth lower gain antennas will be more suitable for urban or suburban locations.
| Colour | Black |
|---|---|
| Frequency Range | 330-360MHz, 380-400MHz, 380-410MHz, 400-430MHz, 410-430MHz, 420-456MHz, 430-472MHz, 450-470MHz, UNCUT |
| ELECTRICAL DATA | |
|---|---|
| Pattern | Omnidirectional |
| Max Input Power(W) | 60 |
| Frequency Range | Gain | Check the part number table |
| Cellular LTE Elements | No |
| WIFI Elements | No |
| UHF Elements | No |
| GPS DATA | |
| Number of GPS Elements | No |
| MECHANICAL DATA | |
| Colour | Black |
| Height | max: 554 (mm) | 21.81 (in) |
| Diameter | 18 (mm) | 0.71 (in) |
| Operating Temperature | -40°/ +80°C (-40.0°/ +176.0°F) |
| CABLE DATA | |
| Quantity of Whip Cable | 1 |
| TECHNOLOGY DATA | |
| Technology | VHF; UHF; TETRA |
