Description
A flexible quarter wave antenna for VHF frequencies with M6 x 0.75 termination for Panorama bases and OEM ‘Beesting’ styling. This antenna features a flexible construction a shock spring over-moulded in TPU. This provides damage resistance without compromising RF performance. The AFBQ range is suitable for use with all Panorama GPS combination bases.
Technical Specifications
Part numbers AFBQ, AFBQ-152, AFBQ-157, AFBQ-224, AFBQ-H4/H4A/H5/H6/H6A/H7. VHF flexible quarter-wave whip; black; peak 2 dBi on tuned models; 100 W; max height 530 mm, 12.5 mm diameter; −40 to +80 °C; M6×0.75 base termination; suitable for Panorama GPS combination bases.
Technical Datasheet (official Panorama source)
Product overview
A flexible quarter wave antenna for VHF frequencies with M6 x 0.75 termination for Panorama bases and OEM ‘Beesting’ styling .
This antenna features a flexible construction a shock spring over-moulded in TPU. This provides damage resistance without compromising RF performance.
The AFBQ range is suitable for use with all Panorama GPS combination bases.
Available selections
| Colour | Black |
|---|
| Frequency Range | 138-155MHz 141-151MHz 149-159MHz 155-174MHz 156-162MHz 162-174MHz 224MHz UNCUT 150-164MHz 152MHz |
|---|
Models and configurations
SKU; Colour | Height (mm) | VHF | Frequency Range | Gain
| AFBQ | - Black | 530mm | Yes | UNCUT
|
|---|
| AFBQ-152 | - Black | 458mm | Yes | 152MHz | 2dBi
|
|---|
| AFBQ-157 | - Black | 445mm | Yes | 150 – 164MHz | 2dBi
|
|---|
| AFBQ-224 | - Black | 297mm | Yes | 224MHz | 2dBi
|
|---|
| AFBQ-H4 | - Black | 484mm | Yes | 141 – 151MHz | 2dBi
|
|---|
| AFBQ-H4A | - Black | 484mm | Yes | 138 – 155MHz | 2dBi
|
|---|
| AFBQ-H5 | - Black | 452mm | Yes | 149 – 159MHz | 2dBi
|
|---|
| AFBQ-H6 | - Black | 434mm | Yes | 156 – 162MHz | 2dBi
|
|---|
| AFBQ-H6A | - Black | 429mm | Yes | 155 – 174MHz | 2dBi
|
|---|
| AFBQ-H7 | - Black | 414mm | Yes | 162 – 174MHz | 2dBi
|
|---|
Configuration options
| Option | Available values |
|---|
| Colour | Black |
|---|
| Frequency Range | 138-155MHz, 141-151MHz, 149-159MHz, 155-174MHz, 156-162MHz, 162-174MHz, 224MHz, UNCUT, 150-164MHz, 152MHz |
|---|
