AFM[W] | Robust UHF 1/4 Wave Whip Antenna

Model / SKU: AFM[W]

AFM[W] | Robust UHF 1/4 Wave Whip Antenna

A Robust flexible quarter wave whip antenna for UHF frequencies with M6 x 0.75 terminations for Panorama bases. This antenna is injection moulded over with tough TPU material. This provides damage resistance without compromising RF performance. The AFM range is suitable for use with Panorama GPSB, GPSD, and GPSK bases. The AFM range is supplied in black and the AFMW range is supplied in white.

Description

Product overview

Product Features

Robust and flexible 1/4 wave suitable for Panorama’s M6 x 0.75 base termination Fully over moulded with TPU material Can be tuned to various different UHF frequencies Covers 380-520MHz (banded) as well as 762-870MHz frequencies Omni-directional with 2dBi peak gain 100W maximum input power

Benefits

Flexible antenna for vehicle installs Available in black or white plastic Can fit a range of different bases from Panorama

Application

Vehicle Communications Two-way radio

Additional information

Colour	Black, White
Frequency Range	380-400MHz, 380-430MHz, 406-472MHz, 410-430MHz, 410-470MHz, 450-470MHz, 450-512MHz, 470-512MHz, 762-870MHz, 868MHz, UNCUT

ELECTRICAL DATA
Pattern	Omnidirectional
Max Input Power(W)	100
Frequency Range \| Gain	Check the part number table
Cellular LTE Elements	No
WIFI Elements	No
UHF Elements	No
GPS DATA
Number of GPS Elements	No
MECHANICAL DATA
Colour	Black; White
Height	max: 197 (mm) \| 7.76 (in)
Diameter	12.4 (mm) \| 0.49 (in)
Operating Temperature	-40°/ +80°C (-40.0°/ +176.0°F)
CABLE DATA
Quantity of Whip Cable	1
TECHNOLOGY DATA
Technology	UHF; TETRA

Available selections

Colour	Black White
Frequency Range	380-400MHz 380-430MHz 406-472MHz 410-430MHz 410-470MHz 450-470MHz 450-512MHz 470-512MHz 868MHz UNCUT 762-870MHz

Models and configurations

SKU; Colour | Height (mm) | UHF | Frequency Range | Gain

AFM	Black \| 197mm \| Yes \| UNCUT
AFM-835	Black \| 75.5mm \| Yes \| 762 – 870MHz \| 2dBi
AFM-868	Black \| 73mm \| Yes \| 868MHz \| 2dBi
AFM-S1	Black \| 162mm \| Yes \| 380 – 400MHz \| 2dBi
AFM-S2	Black \| 152mm \| Yes \| 410 – 430MHz \| 2dBi
AFM-S4	Black \| 134mm \| Yes \| 450 – 470MHz \| 2dBi
AFM-TET	Black \| 158mm \| Yes \| 380 – 430MHz \| 2dBi
AFM-U1	Black \| 144mm \| Yes \| 410 – 470MHz \| 2dBi
AFM-U2	Black \| 127mm \| Yes \| 450 – 512MHz \| 2dBi
AFM-UT	Black \| 144mm \| Yes \| 406 – 472MHz \| 2dBi
AFM-W	Black \| 124mm \| Yes \| 470 – 512MHz \| 2dBi
AFMW	White \| 197mm \| Yes \| UNCUT
AFMW-835	White \| 75.5mm \| Yes \| 762 – 870MHz \| 2dBi
AFMW-S1	White \| 162mm \| Yes \| 380 – 400MHz \| 2dBi
AFMW-S2	White \| 152mm \| Yes \| 410 – 430MHz \| 2dBi
AFMW-S4	White \| 134mm \| Yes \| 450 – 470MHz \| 2dBi
AFMW-TET	White \| 158mm \| Yes \| 380 – 430MHz \| 2dBi
AFMW-U1	White \| 144mm \| Yes \| 410 – 470MHz \| 2dBi
AFMW-U2	White \| 127mm \| Yes \| 450 – 512MHz \| 2dBi

Configuration options

Option	Available values
Colour	Black, White
Frequency Range	380-400MHz, 380-430MHz, 406-472MHz, 410-430MHz, 410-470MHz, 450-470MHz, 450-512MHz, 470-512MHz, 868MHz, UNCUT, 762-870MHz

Data material

Datasheet - AFM[W]-835.pdf (PDF)
Datasheet - AFM-[UHF].pdf (PDF)
