AQ[H]B| VHF & UHF 1/4 Wave Whip

Model / SKU: AQ[H]B-VAR

AQ[H]B| VHF & UHF 1/4 Wave Whip

AQ[H]B| VHF & UHF 1/4 Wave Whip

This antenna features a 17-7 PH stainless steel rod with plated brass components and black nylon moulding. When fitted correctly these antennas will have a typical VSWR of 1.5:1 or less. The Panorama mounting system provides a high degree of interchangeability between whips and bases, making them suitable for all applications whether temporary or permanent.

Description

This antenna features a 17-7 PH stainless steel rod with plated brass components and black nylon moulding. When fitted correctly these antennas will have a typical VSWR of 1.5:1 or less. The Panorama mounting system provides a high degree of interchangeability between whips and bases, making them suitable for all applications whether temporary or permanent.

Product overview

This antenna features a 17-7 PH stainless steel rod with plated brass components and black nylon moulding. When fitted correctly these antennas will have a typical VSWR of 1.5:1 or less. The Panorama mounting system provides a high degree of interchangeability between whips and bases, making them suitable for all applications whether temporary or permanent.

Product Features

  • 1/4 wave rigid whip Removable for carwash Hinged & non-hinged versions

Additional information

Colour

Black
Frequency Range

138-155MHz, 139-157MHz, 141-151MHz, 149-159MHz, 155-174MHz, 156-162MHz, 162-174MHz, 174-192MHz, 220-250MHz, 330-334MHz, 350-370MHz, 350-392MHz, 380-400MHz, 380-430MHz, 390-432MHz, 400-430MHz, 406-472MHz, 410-470MHz, 420-456MHz, 430-472MHz, 450-470MHz, 450-512MHz, 606-614MHz, 614-639MHz, 806-870MHz, 910MHz, UNCUT
ELECTRICAL DATA
PatternOmnidirectional
Max Input Power(W)50
Frequency Range | GainCheck the part number table
Cellular LTE ElementsNo
WIFI ElementsNo
UHF ElementsNo
GPS DATA
Number of GPS ElementsNo
MECHANICAL DATA
ColourBlack
Heightmax: 620 (mm) | 24.41 (in)
Diameter17 (mm) | 0.67 (in)
Operating Temperature-40°/ +80°C (-40.0°/ +176.0°F)
CABLE DATA
Quantity of Whip Cable1
TECHNOLOGY DATA
TechnologyVHF; UHF; TETRA

Available selections

ColourBlack
Frequency Range138-155MHz 139-157MHz 141-151MHz 149-159MHz 155-174MHz 156-162MHz 162-174MHz 174-192MHz 220-250MHz 330-334MHz 350-370MHz 350-392MHz 380-400MHz 380-430MHz 390-432MHz 406-472MHz 410-470MHz 430-472MHz 450-470MHz 450-512MHz UNCUT 400-430MHz 420-456MHz 606-614MHz 614-639MHz 806-870MHz 910MHz

Models and configurations

SKU; Colour | Height (mm) | VHF | UHF | Frequency Range | Gain

AQB
  • Black | 620mm | Yes | No | UNCUT
AQB-910
  • Black | 86mm | No | Yes | 910MHz | 2dBi
AQB-H4A
  • Black | 498mm | Yes | No | 138 – 155MHz | 2dBi
AQB-H5
  • Black | 476mm | Yes | No | 149 – 159MHz | 2dBi
AQB-H6
  • Black | 461mm | Yes | No | 156 – 162MHz | 2dBi
AQB-H6A
  • Black | 446mm | Yes | No | 155 – 174MHz | 2dBi
AQB-H7
  • Black | 437mm | Yes | No | 162 – 174MHz | 2dBi
AQB-JRC
  • Black | 492mm | Yes | No | 139 – 157MHz | 2dBi
AQB-S
  • Black | 194mm | No | Yes | 350 – 392MHz | 2dBi
AQB-S1
  • Black | 185mm | No | Yes | 380 – 400MHz | 2dBi
AQB-S4
  • Black | 157mm | No | Yes | 450 – 470MHz | 2dBi
AQB-TET
  • Black | 180mm | No | Yes | 380 – 430MHz | 2dBi
AQB-U
  • Black | 160mm | No | Yes | 430 – 472MHz | 2dBi
AQB-U1
  • Black | 169mm | No | Yes | 410 – 470MHz | 2dBi
AQB-U2
  • Black | 151mm | No | Yes | 450 – 512MHz | 2dBi
AQB-UT
  • Black | 170mm | No | Yes | 406 – 472MHz | 2dBi
AQHB
  • Black | 620mm | Yes | No | UNCUT
AQHB-610
  • Black | 120mm | No | Yes | 606 – 614MHz | 2dBi
AQHB-627
  • Black | 116mm | No | Yes | 614 – 639MHz | 2dBi
AQHB-H4
  • Black | 500mm | Yes | No | 141 – 151MHz | 2dBi
AQHB-H4A
  • Black | 498mm | Yes | No | 138 – 155MHz | 2dBi
AQHB-H5
  • Black | 476mm | Yes | No | 149 – 159MHz | 2dBi
AQHB-H6
  • Black | 461mm | Yes | No | 156 – 162MHz | 2dBi
AQHB-H6A
  • Black | 446mm | Yes | No | 155 – 174MHz | 2dBi
AQHB-H7
  • Black | 437mm | Yes | No | 162 – 174MHz | 2dBi
AQHB-JRC
  • Black | 492mm | Yes | No | 139 – 157MHz | 2dBi
AQHB-K5
  • Black | 403mm | Yes | No | 174 – 192MHz | 2dBi
AQHB-L
  • Black | 318mm | Yes | No | 220 – 250MHz | 2dBi
AQHB-R1
  • Black | 221mm | No | Yes | 330 – 334MHz | 2dBi
AQHB-R2
  • Black | 200mm | No | Yes | 350 – 370MHz | 2dBi
AQHB-S1
  • Black | 194mm | No | Yes | 350 – 392MHz | 2dBi
AQHB-S4
  • Black | 157mm | No | Yes | 450 – 470MHz | 2dBi
AQHB-S5
  • Black | 88mm | No | Yes | 806 – 870MHz | 2dBi
AQHB-T
  • Black | 178mm | No | Yes | 390 – 432MHz | 2dBi
AQHB-T1
  • Black | 176mm | No | Yes | 400 – 430MHz | 2dBi
AQHB-T2
  • Black | 165mm | No | Yes | 420 – 456MHz | 2dBi
AQHB-TET
  • Black | 183mm | No | Yes | 380 – 430MHz | 2dBi
AQHB-U
  • Black | 160mm | No | Yes | 430 – 472MHz | 2dBi
AQHB-U1
  • Black | 169mm | No | Yes | 410 – 470MHz | 2dBi
AQHB-U2
  • Black | 155mm | No | Yes | 450 – 512MHz | 2dBi
AQHB-UT
  • Black | 170mm | No | Yes | 406 – 472MHz | 2dBi

Configuration options

OptionAvailable values
ColourBlack
Frequency Range138-155MHz, 139-157MHz, 141-151MHz, 149-159MHz, 155-174MHz, 156-162MHz, 162-174MHz, 174-192MHz, 220-250MHz, 330-334MHz, 350-370MHz, 350-392MHz, 380-400MHz, 380-430MHz, 390-432MHz, 406-472MHz, 410-470MHz, 430-472MHz, 450-470MHz, 450-512MHz, UNCUT, 400-430MHz, 420-456MHz, 606-614MHz, 614-639MHz, 806-870MHz, 910MHz
