Model / SKU: PUG-TNC
The PUG range of 1/2 wave antennas are ground plane independent and
offer gain for applications requiring consistent performance.
The antenna transformer is encased in a robust polyamide moulding with a
flexible radiating element and is supplied with a TNC connector.
The PUG range of 1/2 wave antennas are ground plane independent and offer gain for applications requiring consistent performance. The antenna transformer is encased in a robust polyamide moulding with a flexible radiating element and is supplied with a TNC connector.
The PUG range of 1/2 wave antennas are ground plane independent and offer gain for applications requiring consistent performance.
The antenna transformer is encased in a robust polyamide moulding with a flexible radiating element and is supplied with a TNC connector.
| Colour | Black |
|---|---|
| Frequency Range | 340-380MHz, 380-400MHz, 380-430MHz, 405-439MHz, 410-430MHz, 425-460MHz, 425-465MHz, 430-470MHz, 433MHz, 438-472MHz, 458MHz, 465MHz, 470-510MHz |
| ELECTRICAL DATA | |
|---|---|
| Pattern | Omnidirectional |
| Max Input Power(W) | 5 |
| Frequency Range | Gain | Check the part number table |
| Cellular LTE Elements | No |
| WIFI Elements | No |
| UHF Elements | No |
| GPS DATA | |
| Number of GPS Elements | No |
| MECHANICAL DATA | |
| Colour | Black |
| Height | max: 464 (mm) | 18.27 (in) |
| Diameter | 16 (mm) | 0.63 (in) |
| Operating Temperature | -40°/ +80°C (-40.0°/ +176.0°F) |
| CABLE DATA | |
| Quantity of Whip Cable | 1 |
| TECHNOLOGY DATA | |
| Technology | UHF; 433MHz; TETRA |
