Model / SKU: WMM2G[G]-6-60
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-6-SAB-260.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna - Image 2](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-1-Main-View-with-pole.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna - Image 3](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-2-Main-View.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna - Image 4](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-3-Front-View.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna - Image 5](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-4-Side-View.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
![WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna - Image 6](https://wirelesssolutions.net.au/wp-content/uploads/2026/10/WMM2GG-6-60-5-SAB-186.jpg "WMM2G[G]-6-60 | 2×2 MiMo 4G/5G Directional Antenna")
The WMM2G[G]-6-60 is a high gain directional 2×2 MiMo antenna for 4G and 5G networks. It incorporates two wideband element assemblies in a single housing and is designed to support fixed-site client devices.
It offers a 6dBi peak gain for 617- 960MHz and a 9dBi peak gain for 1710-6000MHz. The weather-resistant housing is designed for wall or mast mounting with the supplied hardware.
The standard WMM2G[G]-6-60-5SP version has 5m length ultra-low loss CS32 type coaxial cables which eliminate exposed connector joints and simplifies the installation process.
The WMM2G[G]-6-60-05NJ version has 50cm length cables, fitted with N-type jacks, which is ideal for installations that require a longer cable run, where Panorama’s CS240 or CS400 type coaxial cable can be used to minimise the cable insertion loss.
The WMM2G[G]-6-60 is a value-added product for network operators and service providers by improving the link resilience to the router, achieving increased data rates for the subscriber, resulting in customer satisfaction and retention.
The WMM2G[G]-6-60 is a high gain directional 2×2 MiMo antenna for 4G and 5G networks. It incorporates two wideband element assemblies in a single housing and is designed to support fixed-site client devices. It offers a 6dBi peak gain for 617- 960MHz and a 9dBi peak gain for 1710-6000MHz. The weather-resistant housing is designed for wall or mast mounting with the supplied hardware.
The WMM2G[G]-6-60 is a high gain directional 2×2 MiMo antenna for 4G and 5G networks. It incorporates two wideband element assemblies in a single housing and is designed to support fixed-site client devices.
It offers a 6dBi peak gain for 617- 960MHz and a 9dBi peak gain for 1710-6000MHz. The weather-resistant housing is designed for wall or mast mounting with the supplied hardware.
The standard WMM2G[G]-6-60-5SP version has 5m length ultra-low loss CS32 type coaxial cables which eliminate exposed connector joints and simplifies the installation process.
The WMM2G[G]-6-60-05NJ version has 50cm length cables, fitted with N-type jacks, which is ideal for installations that require a longer cable run, where Panorama’s CS240 or CS400 type coaxial cable can be used to minimise the cable insertion loss.
The WMM2G[G]-6-60 is a value-added product for network operators and service providers by improving the link resilience to the router, achieving increased data rates for the subscriber, resulting in customer satisfaction and retention.
| Colour | White |
|---|---|
| 4G/5G | 2 x 2 MIMO |
| GPS | 1 Module, No |
| Cable Length | Between 5m & 10m |
| Connector (LTE) | N (f), N (m), SMA (m) |
| Connector (GPS) | N (f), No Connector, SMA (m) |
| ELECTRICAL DATA | |
|---|---|
| Pattern | Directional |
| Max Input Power(W) | 50 |
| Cellular LTE Elements | 2 x 2 MIMO |
| WIFI Elements | No |
| UHF Elements | No |
| GPS DATA | |
| GPS Frequency Range | 1560-1612MHz |
| LNA GAIN (dB) | 26 |
| Number of GPS Elements | No; 1 Module |
| MECHANICAL DATA | |
| Colour | White |
| Length | 307 (mm) | 12.09 (in) |
| Width | 85 (mm) | 3.35 (in) |
| Height | 507 (mm) | 19.96 (in) |
| Operating Temperature | -45°/ +80°C (-49.0°/ +176.0°F) |
| CABLE DATA | |
| Cable Length – LTE | 5 (m) | 16.40 (ft) |
| Cable length – GPS | 5 (m) | 16.40 (ft) |
| Cable Type (LTE) | FR CS32 |
| Cable Type (GPS) | CS29 |
| TERMINATION DATA | |
| Connector (GPS) | N (f); SMA (m) |
| Connector (LTE) | N (f); N (m); SMA (m) |
| MOUNTING DATA | |
| Mounting Type Fixed | Desk; Mast; Wall |
| Mounting Methods | Desk; Mast; Wall |
| APPROVALS DATA | |
| IP Rating | IP65 |
| Cable Flammability | EN45545-2 HL3; UN ECE R118; EN6722 |
| TECHNOLOGY DATA | |
| Technology | 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; GPS; GNSS |
